When the icon appears in the display interface, it means that the parameters can be set.
Long press the MENU key for 1s, then icon flashes, press OK to change the parameter.
6.3.1 Low voltage protection
6.3.2 Low voltage reconnect
①Battery voltage control
②Battery capacity control
Low voltage protection setting range：
10.8~11.8V/21.6~23.6V(default: 11.2/22.4/V).
Low voltage reconnect setting range：
11.4~12.8V/22.8~25.6V(default : 11.8/23.6V).
When the LCD shows as the left, press the MENU key for 1s, the icon
flashes, you can set the controller low voltage protection.'s
When the LCD shows as the left, press the MENU key for 1s, the icon
flashes, you can set the controller low voltage reconnect.'s
When the LCD shows as the left, press the MENU key for 1s, the icon
flashes, you can press OK to clear the Bluetooth device password set by
the mobile app.
6.3 Parameters setting
1.Lithium Battery
1.Lithium Battery
2.Liquid, Gel and AGM Battery
2.Liquid, Gel and AGM Battery
When the battery type is lithium battery, the low-voltage protection
setting range is 9.0-30.0V (default: 10.6V).
When the battery type is lithium battery, the low-voltage reconnect
setting range is 9.6-31.0V (default: 12.0V).
The low voltage protection of the controller can be divided into two
types: battery voltage control and capacity control.
11.0~11.6V/22.0~23.2V
11.1~11.7V/22.2~23.4V
11.2~11.8V/22.4~23.6V
11.4~11.9V/22.8~23.8V
11.6~12.0V/23.2~24.0V
Display Low voltage protection range
The low voltage recovery voltage(LVR) should be higher than the low voltage protection
voltage(LVD) at least 0.6/1.2V, if you want to improve LVD, you should first improve LVR.
6.3.3 Clear Bluetooth Device Password
For device passwords, please refer to Bluetooth APP instructions.
