Part name - Installation before use
1. Top board
2. Control panel
3. Door
4. Front vent cover
5. Cabinet
6. Filter
7. Power lead
8. Door lock
9. Tumbling drum
NOTICE BEFORE USE
Power source and grounding
The dryer employs alternating current with the rated voltage and frequency.
When the voltage fl uctuates between 10% of rated voltage, the dryer can
work normally. A special seperate power socket next to the dryer is best for
convenience and safety. The method for connection of the socket is as the
fi gure below.
Installation before use
Precautions
Do not install or store the dryer where it will
be exposed to water or the weather.
Please install the dryer in a ventilated place
for better air circulation to avoid overheating.
A minimum of 10cm around the unit is
recomended.
Damp clothes have to be dehydrated well
before putting them into the dryer.
Ensure that there are no fl ammable liquids
near the dryer whilst in motion. Do not start
the dryer if there is any leakage / spillage
the dryer if there is any leakage / spillage
near the unit.
Do not use the unit to dry any clothes
containing any fl ammable liquids or
gasoline. Never insert any combustible
item inside the dryer.
Do not operate the unit when it is damaged,
malfunctioning, partially disassembled or has
missing or broken parts.
While the dryer is in motion the unit may
become hot. To avoid any injury, this
dryer is not intended to be use by infi rm
persons or children.
Please take care when using the unit. Do
not operate the unit when your hand/feet
is wet.
03
04
This appliance is not intended for use by young children or infi rm persons unless they have been
adequately supervised by a responsible person to ensure that they can use the appliance safely.
Young children should be supervised to ensure that they do not play with the appliance.
