1.5 Wall Mount – LumiNode 2
The LumiNode 2 can be mounted to a concrete or wood wall by using applicable
screws and anchors. Make sure that the screw head diameter is between 8 – 10mm
and the screw length is at least 40mm in order to make a strong wall connection.
Drill 4 holes, at the correct distance in both directions as indicated in the picture
on the next page (L). Mount the device in such way that the Ethernet and DMX
ports are facing sideways, and the chassis side is perpendicular to the ground.
Ø 8-10mm
≥ 40mm
