Belt
Pulley cover
Adjusting hole
Standard
screwdriver
4.Tighten the screws slightly. To tension the belt, press down the
motor pulley with a screwdriver so the belt is tensioned.
5. Tighten the three screws.
6. Check the tension by pressing together the belt using two fing-
ers. It should be possible to press together the belt about 6 mm.
NOTE! If the belt is tensioned too much, this can give an
increased noise level and also overload the motor. Too little ten-
sion will cause the belt to slip.
7. Refit the belt guard.
40
