Luna BBD 100 - Page 89

87
BBD 100 part list
No. Part No. Description No. Part No. Description
1 Knob 36 Label,Scale
2 Washer,Rubber 37 Cord w/Plug
3 Washer,Notched 38 Motor (1/3 HP)
4 Bed 39 Connector,Wire
5 M5*0.8-35 Flat Cross Screw 40 Hex M6*1.0 Nut
6 M6*1.0-14 Screw Hex 41 Base
7 Ext. M6 Lock washer 42 Belt,Timing Drive
8 6.5*17.8*1.6 Washer 43 Flat Cross Screw
9 Support,Work 44 M5*0.8-10 Washer,Countersink
10 4"*36" Sanding Belt 45 Pulley,Drive
11 M5 Lock washer,Helical 46 M6*1.0-25 Pan Hd Screw
12 M5*0.8-8 Pan Hd Screw 47 M6*12*1.6 Washer
13 Drum,Drive 48 Pulley,Drive
14 M8*1.25-10 Socket Set Screw 49 M5*0.8-25 Flat Hd Screw
15 Cap,Bearing 50 Support,Bearing
16 Bearing w/Felt Washer 51 Cover,Belt
17 Spacer,Bearing 52 Support,Bed
18 Housing Switch 53 M8*1.25 Nut,Square
19 Ext. M5 Lockwasher 54 Bumper,Rubber
20 M5*0.8-16 Pan Hd Screw 55 Hex Soc. Cap Screw
21 Switch 56 M8*1.25 Ball Bearing
22 Lead 57 M12 Retaining Ring
23 Pan Cross Screw 58 Shaft,Drive
24 Type "AB" M4.2*1.4-30 Cover,Switch Box 59 M5*0.8 Hex Flange Nut
25 Capacitor 60 Spacer,Guide
26 6" Sandpaper Pad 61 Spring,Index
27 Pan Cross Screw 62 Guide,Drum
28 M6*1.0-12 Lockwasher,Helical 63 Shaft,Idler
29 Disc 64 Drum,Idler
30 Type "AB" Pan Hd Screw 65 Lever,Tension
31 M4.2*1.4-12 Guard,Disc 66 Spring,Tension
32 Shroud,Disc 67 Spacer,Lever
33 Collector,Dust 68 M5*15*1.2 Washer
34 Table 69 Assis. Working table
35 Support,Table
