206450108
BBD 150
art list
No.
Part No. Description No. Part No. Description
1 152.4±1.524X1219.2±1.524 Sanding belt 40 Motor cover
2 Bed 41 Safety guard, sanding belt lower
3 Knob 42 3.5X16mm Pan head screw
4 6mm Washer 43 M6X145 Thread
5 Wing screw 44 Rubber sleeve
6 M6X16 Sunk head screw 45 Support stem
7 Work table for belt 46 Lock base sander belt
8 Work support, sander belt 47 Motor
9 Lock pin, work support 48 M8X16 Hex head screw
10 Wing nut 49 8mm Lock washer
11 5mm Lock washer-helical 50 Drive pulley
12 M5X14 Pan head Screw 51 6mm Countersink washer
13 M5X16 Pan head screw 52 3.5X35mm Flat cross screw
14 Switch housing 53 Pulley cover
15 No-volt switch 54 Timing belt
16 M4X10 screw 55 Drive pulley
17 Bearing spacer w/ bearing 56 M5X40 Flat head screw
18 Bearing cap 57 Bearing support
19 M8X10 Socket head screw 58 Lock plate sander plate
20 Drive drum 59 M8X25 Hex socket cap screw
21 Cover, switch housing 60 15mm Retaining ring
22 Pad-254mm dia. Sandpaper 61 Ball bearing
23 M6X16 Screw-pan cross 62 Drive shaft
24 Disc 63 M5X16 Pan head screw
25 Support, sanding disc 64 5mm Rubber washer
26 M4X46 Tapping screw 65 Tension lever
27 Disc guard 66 Lever spacer
28 Disc shroud 67 6mm Rubber washer
29 M6 Hex nut 68 Index spring
30 M6X16 Pan head screw 69 Rubber bushing
31 Mount, table support 70 12mm Retaining ring
32 Table support 71 Ball bearing
33 Table 72 Idler drum
34 Dust collector 73 Idler shaft
35 3.5X22mm Pan head screw 74 Drum guide
36 Clamp handle 75 Index spring
37 Handle 76 Power cord w/plug
38 M6X16 Pan head screw 77 “D” shape rubber bushing
39 Cast Base
