4-12
CDA3000 Operation Manual
4 Commissioning
Start drive
SFC setting
SFC is preset, and requires no further optimization for standard
applications.
Note:
For special settings to optimize
• the speed control loop
• the torque at low speeds
refer to the Application Manual.
Step Action Comment
1
Close ENPO contact and set a low
reference value with R1.
ENPO active enables power stage.
2
Start drive by closing the STL or
STR contact.
STL = Start counter-clockwise
STR = Start clockwise
3
Check direction of rotation of motor
shaft.
If direction is wrong check motor
connection (phase sequence).
4
Brake drive by opening the start
contact.
Drive brakes down to a standstill.
5
Open ENPO contact.
ENPO inactive safely disables power
stage.
Commissioning is complete.
Document Order designation Language Download
Application Manual
0840.02B.0 German
Website
www.lust-tec.de
0840.22B.0 English
