Application Note #480
5 Technical Support — 800.523.9466
Dimming Features
The Maestro® Occupancy Sensor C•L® Dimmer has features that allow the user to change aspects of the dimming
functionality. The features include:
• Preset Light Level
• Manual Fade ON Time
• Manual Fade OFF Time
• Delayed Fade to OFF
• Enable/Disable Indicator Lights
• Low-End Trim
• High-End Trim
Explanations of the features can be found on pages 8-16 of this document. Programming can be found on pages 6-8.
Sensor Dimmer Coverage Area
Horizontal Beam Diagram
5 ft
(1.5 m)
5 ft
(1.5 m)
0
10 ft
(3 m)
10 ft
(3 m)
15 ft
(4.5 m)
15 ft
(4.5 m)
20 ft
(6 m)
20 ft
(6 m)
25 ft
(7.5 m)
25 ft
(7.5 m)
30 ft
(9 m)
30 ft
(9 m)
Vertical Beam Diagram
5 ft
(1.5 m)
0
10 ft
(3 m)
10 ft
(3 m)
15 ft
(4.5 m)
15 ft
(4.5 m)
20 ft
(6 m)
20 ft
(6 m)
25 ft
(7.5 m)
25 ft
(7.5 m)
30 ft
(9 m)
30 ft
(9 m)
4 ft
(1.2 m)
0
NEMA WD7 Test Grid Coverage (High Sensitivity Setting)
5 ft
(1.5 m)
5 ft
(1.5 m)
0
10 ft
(3 m)
10 ft
(3 m)
15 ft
(4.5 m)
15 ft
(4.5 m)
5 ft
(1.5 m)
Major motion coverage: 900 ft( (81 m()
Minor motion coverage: 400 ft( (36 m()
35 ft
(10.7 m)
