Lutron Electronics Caseta DVRF-AS - Table of Contents

2
by Lutron
Table of Contents (continued)
Multi-Location Installation (continued) - If you have three or more switches controlling your lights, follow this procedure to
install your dimmer or switch
With a Wired Accessory
Diva Smart Dimmer with Claro Smart Accessory Switch (DVRF-6L / DVRF-AS): ....................................................... Page 119 - 123
Diva Smart ELV+ Dimmer with with Claro Smart Accessory Switch (DVRF-5NE / DVRF-AS): .................................. Page 124 - 128
Claro Smart Switch with with Claro Smart Accessory Switch (DVRF-5NS / DVRF-AS): ............................................ Page 129 - 133
Adjusting the Low-End Trim - Follow this procedure if you experience performance issues such as flickering,
flashing or other abnormal light behavior when your dimmer is at a low light level
On a Dimmer (PD-6WCL): ...................................................................................................................................................... Page 134
On a PRO Dimmer (PD-10NXD): ............................................................................................................................................Page 136
On an ELV+ Dimmer (PD-5NE): .............................................................................................................................................Page 138
On a Plug-In Lamp Dimmer (PD-3PCL): ......................................................................................................................... Page 140
On a Diva Smart Dimmer (DVRF-6L / DVRF-5NE): ......................................................................................................... Page 142
Adjusting the High-End Trim - Follow this procedure to adjust the maximum light output allowed by your
dimmer
On a Dimmer (PD-6WCL): ................................................................................................................................................ Page 135
On a PRO Dimmer (PD-10NXD): ..................................................................................................................................... Page 137
On an ELV+ Dimmer (PD-5NE): ....................................................................................................................................... Page 139
On a Plug-In Lamp Dimmer (PD-3PCL): ......................................................................................................................... Page 141
Converting a Plug-In Lamp Dimmer to a Switch to Control Non-Dim Loads (Lights Only) (PD-3PCL):
Follow this procedure if you would like your plug-in lamp dimmer to act as a switch for non-dimmable lighting loads ...... Page 143
Setting Dimmer Phase on a Caséta Wireless ELV+ Dimmer (PD-5NE) ....................................................... Page 144
Setting Dimmer Phase on a Caséta Wireless ELV+ Dimmer (DVRF-5NE) ................................................. Page 145
Removing Paired Pico Remote Controls - Follow this procedure if you need to remove paired Pico remote
controls or reset your dimmer or switch to its factory default settings
From a Dimmer (PD-6WCL/PD-10NXD/PD-5NE/PD-3PCL): ........................................................................................ Page 146
From a Switch (PD-5WS-DV/PD-5ANS/PD-6ANS): ....................................................................................................... Page 147
From a Fan Control (PD-FSQN): ..................................................................................................................................... Page 148
From a Lutron Shade: ...................................................................................................................................................... Page 149
From a Diva Smart Dimmer (DVRF-6L / DVRF-5NE): ..................................................................................................... Page 151
From a Claro Smart Switch (DVRF-5NS): ........................................................................................................................ Page 152
Changing the Favorite Light Level on a Pico Remote Control - Follow this procedure to change the
light level your dimmer recalls when you press the "Favorite" button on your Pico remote control ....................................... Page 153
Changing the Favorite Light Level on an ELV+ Dimmer (PD-5NE) - Follow this procedure to change the
light level your dimmer recalls when you press the "Favorite" button on your Phase Selectable Dimmer ............................. Page 154
Changing the Favorite Fan Speed Setting on a Fan Control (PD-FSQN) - Follow this procedure to
change the fan speed your control recalls when you press the "Favorite" button on your Fan Control ................................. Page 155
Installing a LUT-MLC Load Adapter with an Switch (PD-5WS-DV) - The LUT-MLC is provided
to help ensure proper operation of the Caséta Wireless switch with LED, fluorescent, and ELV lighting loads..................... Page 156
Motion Sensor Placement and Coverage (PD-OSENS / PD-VSENS) - ................................................. Page 157
Motion Sensor Advanced Features (PD-OSENS / PD-VSENS) - ........................................................... Page 163
Troubleshooting - ............................................................................................................................................................ Page 164
