Time base Quartz crystal.
Circuit Exclusive one-chip of microcomputer
LSI circuit.
Photo Tach. * Less than 1 mW.
Laser light * Class 2 laser diode.
source Red Wave length is 645 nm
approximately.
Operating 0 to 50 ( 32 to 122 ).℃℉
Temperature
Operating Less than 80% R.H.
Humidity
Memory Memorize Last/Max./Min. value
with recall.
Data Output RS232 PC serial interface.
Battery 4 x 1.5V AAA ( UM4 ) batteries.
Power
Photo tachometer :
Consumption Approx. DC 20 mA.
Contact tachometer :
Approx. DC 9.5 mA.
Size 165 x 50 x 33 mm.
( 6.5 x 2.0 x 1.3 inch ).
Weight 182 g ( 0.4 LB ).
* Weight is cluded the batteries.
Accessories Reflecting tape marks
Included ( 600 mm )................................
1 PC.
Optional * Carrying case, CA-52A
Accessory * RS232 cable, UPCB-02.
* Data Acquisition software,
SW-U801-WIN.
3
