1. FEATURES
The Digital Stroboscope is a microprocessor circuit design,
high accuracy, digital readout, light duty, that is ideal for
inspecting and measuring the speed of moving gears, fans,
centrifuges, pumps, motors and other equipment used in
general industrial maintenance, production, quality control,
laboratories and as well as for schools and colleges for
demonstrating strobe action.
2. SPECIFICATIONS
2-1 General Specification
Display 0.4" LED, 4 digits.
Stroboscopic 100 to 10,000 flashes per
Flash Rate minute (FPM).
Accuracy ( 0.05% + 1 digit ).
Spec. tested under the environment
RF Field Strength less than 3 V/M &
frequency less than the 30 MHz only.
Resolution 0.1 FPM/RPM ( less than 1,000 FPM/RPM )
1 FPM/RPM ( 1,000 to 9,999 FPM/RPM ).
10 FPM/RPM ( over 10,000 FPM/RPM )
Sampling Time 1 second.
Range Select High/Low range
Low range : Approx. 100.0 to 1,200 RPM
High range : Approx. 1,000 to 10,000 RPM
Circuit One chip of microcomputer LSI circuit &
crystal control time base
1
