3. FRONT PANEL DESCRIPTION

Fig. 1

Symbol :

3-1 Power On/Off Switch 1 = On

3-2 Low/High Range Select Switch 0 = Off

3-3 Fine Adjust Knob

3-4 Coarse Adjust Knob

3-5 Flash Tube

3-6 Auto Range Indicator

3-7 Display

3-8 Power Cord Input Socket

3-9 Power Cord Connector

3-10 Power Cord Plug
