Lutron Electronics DT-2239A User Manual

Power Supply 110 Vac 10%, 50/60 Hz.
220 Vac 10%, 50/60 Hz.
230 Vac 10%, 50/60 Hz.
240 Vac 10%, 50/60 Hz.
Power Less than 30 Watt.
Consumption
Operating Temp. 0 to 50 ( 32 to 122 ).℃℉
Operating Less than 80% R.H.
Humidity
Dimension 21 x 12 x 12 cm (8.3 x 4.8 x 4.8 inch).
Weight 1 Kg/2.2 LB.
Housing Compact and impact plastic injection
case with plastic mirror type reflector.
Calibration Crystal time base and microprocessor
circuit, no external calibration process
required.
Accessories Operation manual...................
.
1 PC
Included Power cord.............................
.
1 PC
2-2 Flash Tube Specification
Flash tube Xenon lamp.
Flash Duration Approximately 60 to 1000
microseconds.
Flash color Xenon white 6,500 K degree.
Flash energy 4 Watts-seconds (joules).
Beam Angle 80
Flash tube It may be necessary to change the
replacement xenon flash tube if the instrument starts
to flash irregularly at speeds of 3600
RPM/FPM or more.
Operating duty For prolonged life and safe operation,
Cycle please adhere to the following duty
cycle :
Below 3,000 RPM - 30 Minutes.
Above 3,000 RPM - 5 Minutes.
* Always allow a 10 minute cooling off
period between cycles.
2
