Standard Instruction Manual......................... 1 PC.
Accessories Soil pH electrode, PE-06HD............. 1 PC.
pH 4.0 buffer solution, PH-04A.......
1 PC.
Optional * Soft carrying case with sash
Accessories ( 210 x 110 x 55 mm ),
Model : CA-05A
* Hard carrying case
( 280 x 195 x 65 mm ), Model : CA-06
2-1 Soil pH Electrode ( included )
pH Measuring 1 to 13 pH ( typical 0 to 14 pH ).
Range
pH Operation 5 to 60 ( 41 to 140 ).℃℉
Temperature
pH Electrode Combination type.
Structure
Reference Ag/AgCl, Double Junction.
of pH
Electrode
Zero Potential 7± 1 pH.
for pH Value
Repeatability 0.05 pH.
Response time 2 minutes.≧
Body Material Epoxy.
Connector BNC.
Mechanical With protection bottle ( soaker
Protection bottle ) on the electrode head.
Weight 68 g ( including cable & socket ).
Dimensions Body length - 160 mm.
Body Dia. - 12 mm.
Cable length - 1000 mm.
3
