Lutron Electronics VB-8213 - 9.1 Data Format and RS232 Settings

Each digit indicates the following status :
D0 End Word
D1 & D8 Display reading, D1 = LSD, D8 = MSD
For example :
If the display reading is 1234, then D8 to
D1 is : 00001234
D9 Decimal Point(DP), position from right to the
left
0 = No DP, 1= 1 DP, 2 = 2 DP, 3 = 3 DP
D10 Polarity
0 = Positive 1 = Negative
D11 & D12 Annunciator for Display
= 92 = 97
mm/s = 93 cm/s = 95 inch/s = 98
mm = 94 inch = 96 g = 57
D13 When send the upper display data = 1
When send the lower display data = 2
D14 4
D15 Start Word
RS232 setting
Baud rate 9600
Parity No parity
Data bit 8 Data bits
no.
Stop bit 1 Stop bit
18
