Lycoming IO-360-N1A User Manual

IO-360-N1A Engine Installation and Operation Manual
© 2016 Avco Corporation. All Rights Reserved Engine Installation
February 2016 Page 17
ENGINE INSTALLATION
Engine Installation Overview
The installation instructions in this manual are basic guidelines. When installing the engine in the
airframe, follow the airframe manufacturer’s installation instructions.
NOTICE: All requirements identified in the chapter “Requirements for Engine Installation” must
be completed before engine installation.
This engine can be installed in aircraft in Table 1.
Table 1
Aircraft Where IO-360-N1A Engines Can Be Installed
FAR Part 23 normal and utility category aircraft up to Class III
NOTICE: This engine cannot be installed in aircraft in Table 2.
Table 2
Aircraft Where IO-360-N1A Engines Cannot Be Installed
Any FAR Part 25 aircraft
Any FAR Part 29 rotorcraft
NOTICE: Installation drawings for this engine are available for purchase from Lycoming Engines.
Refer to Appendix B for ordering information.
To install the engine, refer to the section reference in this chapter for each step in Table 3.
Table 3
Engine Installation Steps and References
Step
Section References in This Chapter
1
Install the Engine on Mounts
2
Connect the Wiring Harness
3
Connect the Linkages
4
Install External Accessories (as necessary)
5
Install Baffling
6
Install the Compressor Belt (as necessary)
7
Install the Propeller
8
Connect Fuel Lines
9
Connect Oil Lines
10
Install Components That Had Been Removed Before Engine Installation
11
Add Oil
12
Add Fuel (to aircraft as necessary)
13
Engine Pre-Oil Procedure
