OPERATORS MANUAL ____________________________________ 31
ENGLISH
Start the engine and let it warm up to the normal using temperature.
Unscrew idle speed screw to obtain the normal idling speed 18002000 rpm.
NOTE: You may not drive snowmobile if the intake silencer is removed, the fuel mixture
becomes too lean.
Adjusting the needle
Fast driving in cold weather (over -20°C) requires that both needles are raised with respect
to the throttle 1-2 steps.
INJECTION OIL SYSTEM
Make sure that there is always enough oil in the oil tank.
Signal light for oil level goes on when the oil level in the tank is low. Check oil and
add if needed.
NOTE: Wipe off any oil spills. Oil is highly flammable.
Oil filter
Check the oil filter monthly.
Check that the oil fileter is not blocked.
WARNING!
Blocked filter may cause serious engine damages. Change the filter yearly.
