Guitar Specifications
30 inch guitar dimensions: 29.9" x 10.2" x 1.7"
30 inch guitar weight: 8.6 lbs.
36 inch guitar dimensions: 34.6" x 11" x 1.7"
36 inch guitar weight: 9.7 lbs.
Number of strings: 6
Body shape: Double cutout
Body wood: Paulownia wood
Orientation: Right-handed
Neck wood: Canadian maple
Joint: Bolt-on
Truss rod: Standard
Fingerboard material: Engineer wood
Number of frets: 21
Inlays: Dots
36 inch guitar pickup controls: 3 way
Control dials: Volume, tone
Bridge: Fixed
Tuner Specifications:
A4 frequency: 440 Hz
Tuning item: Chromatic, guitar, bass, violin, ukulele
Tuning range: 0A (27.5 Hz) - 8C (4186.01 Hz)
Dimensions: 2.1" x 1.1" x 3.1"
Weight: 1.1 oz.
Amplifier Parts:
1. AUX input: Connect an audio source such as an MP3
player or mobile phone to play along with your
recorded music.
2. Instrument input: Connect your guitar with the provided
guitar cable.
3. Grind button: Turn on/off the gain control.
4. Gain: Adjust the amount of the amplifier gain.
5. Bass: Adjust the bass of the output.
6. Treble: Adjust the treble of the output.
7. Volume: Adjust the output volume.
8. Headphones: Connect headphones with a 1/4" TRS jack.
9. Power switch: Turn the amplifier on and off.
Amplifier Specifications:
Power: 20 W
Speaker: 6.5"/4 ohm
Equalization: Treble, bass, gain, grind
Jacks: Headphone, MP3
Dimensions: 11.6" x 11.2" x 4.1"
Weight: 5.7 lbs.
6
1 2 3 4 5 6 7 8 9
