1. Power up the Oxygen 8,using either a 9vDC adapter or using 6 AA batteries.
Set the power switch to the the 9V/Battery setting.If a 9V power adapter is
present,the Oxygen 8 will use power from the adapter.If a 9V adapter is not
present, and the Oxygen 8 has the required battery power, the unit will
power up using the batteries.
2. Make sure that the MIDI port ”transmit” channel within you music
application matches the MIDI “receive” channel of the other instrument.
3. Please refer to the diagram in the section,“Setting Up Your MIDI Studio” for
audio connections.
Default Settings of The Oxygen 8
The Oxygen 8 will always select the following values for their parameters when
the power is turned on.
•Transmit MIDI Channel no.1
• Default Octave will be from C4(60) to C6(84)
• Default After Touch value will be 0
• Default Velocity value will be 0
• Default Reverb Depth value will be 64
•Default Pan Pot value will be 64
• Default Volume value will be 127
• Default CC Data value will be 0
•Default CC no.value will be 0
•Default Control Change (CC-00=0,CC-32=0) message to be transmitted
• Default Program Change (PG=1) message to be transmitted
• Default MIDI-controller knob-assignments (10-17) on MIDI ch.1
Oxygen 8 Panel Features
Top Panel
1. Using the Pitch Bend Wheel:The Pitch Bend wheel is used for raising or
lowering the pitch of a voice during performance, starting from and always
returning to a center “detent” point.The range of pitch values depends on
the sound generator (sound card or module) being used.Please refer to the
15
