67
IDM 510-065-1
K11-R sealing unit
English languageOperation and maintenance manual
Flap length adjustment
This action is necessary to adjust the length of the adhesive tape ap.
The lower and upper ap can be set with different lengths according to the produc-
tion requirements.
– The intervention must be carried out with the machine stopped in safety condi-
tions.
en
on
Warning
Wear the suitable personal protective equipment (gloves) to avoid any cutting haz-
ard.
▀
Upper sealing unit (ap 70 mm)
1. Remove the adhesive tape from the
sealing unit.
2. Components A-B-C must be in-
stalled as shown in the gure.
3. Apply tape stretcher to the adhesive
side of the tape.
4. Guide tape stretcher until the tape
stretcher is beyond the point of tan-
gency of case inlet roller.
5. Cut the adhesive tape close to tape
stretcher.
The part of exceeding adhesive tape
must not be lower than the ap
length.
– Remove components 50 mm in or-
der to obtain a 50 mm ap.
– To obtain a 30 mm ap, request
component E and replace to the
one installed.
▀
Lower sealing unit (ap 70
mm)
1. Lift upper conveyor completely.
This operation is necessary to assist the operations.
2. Remove lower sealing unit
– Repeat the operation according to the procedure described for upper sealing unit.
3. Insert sealing unit into its original housing.
To Next Page
