Installation
1. Caution
- Please keep 100mm distance between main module and enclosure structure for
maintenance and well-ventilation.
- Please avoid installation on the area as follows.
. Locations where the temperature changes drastically and condensation occurs
. Locations where the main unit is exposed to direct sunlight, vibration or impact.
. Locations where strong electrical or magnetic fields are generated.
2. Power Cable Wiring
- Input AC Voltage : 85VAC ~ 264VAC
- Please use noise-cut transformer in case that power source includes noise.
- Please separate power source cable from controller’s power cable or in/out cable.
- Please separate power source cable from communication cable
3. Earth Connection
- The FG and LG port of the TOP main module should always be grounded using the Class
3 Ground
Failing to ground these ports sufficiently could cause electrical shock and malfunction.
- The cable for earth should be more than 2 ㎟
- The earth point be close to the TOP main module and earth cable be short if possible.
