YOUNG DSD
DIGITAL-TO-ANALOG CONVERTER AND PREAMPLIFIER
REVISION 1.1 – march 2014
Copyright © 2014, M2Tech Srl
14
www.m2tech.biz
6) AES/EBU digital input. Connect a source provided with 110 Ohms pro AES/EBU
output. Female three-pole XLR socket.
7-8) S/PDIF digital inputs. Connect sources provided with 75 Ohms S/PDIF outputs.
RCA and BNC female connector terminals are provided.
NOTE: it is possible, while not recommended for highest performance, to
connect a source provided with RCA S/PDIF output to the DAC S/PDIF input
provided with BNC connector, using a suitable BNC-to-RCA adapter (Note that
this optional adapter is not included with the YOUNG DSD
YOUNG DSDYOUNG DSD
YOUNG DSD).
9) Toslink™ optical digital input. Connect a source provided with a Toslink™
digital output. Toslink™ type connector.
10) USB connector. Connect to the USB 2.0 port of a computer using the stock USB
cable. Type “B” female USB connector.
11) Power supply input. Connect the connector from the stock 15V-1.2A.
5.5/2.1mm jack with positive on tip.
