YOUNG DSD
DIGITAL-TO-ANALOG CONVERTER AND PREAMPLIFIER
REVISION 1.1 – march 2014
Copyright © 2014, M2Tech Srl
21
www.m2tech.biz
7. Using the Young DSD
At power on, the YOUNG DSD spends a little time to ensure that all supplies reach their
nominal levels, during which the indication in Fig. 4 is displayed.
M2TECH
YOUNG DSD DAC
Figure 4
After the power on delay is expired, some general operational information is
displayed on the YOUNG DSD display, as shown in Fig. 5 and Fig. 6. The two figures
shown refer to two different volume and source choices. In Fig. 6 the indications “M”
and “PH” are shown to indicate that mute is active and phase is reversed.
VOL: 0.0DB
IN:USB FS:ULOCK
Figure 5
M PH VOL:-32.5DB
IN:RCA FS:ULOCK
Figure 6
