11. Specifications
Inputs: ............................................... AES/EBU on female XLR socket
S/PDIF on female RCA socket
S/PDIF on female BNC socket
Optical on Toslink™ connector
Async USB compatible with USB Audio Device
Class 2/1 “B” type female USB connector
Outputs: ............................................ Balanced analogue on gold-plated male XLR
connectors
Power input:...................................... 5.5/2.1mm jack with positive on tip
Output voltage: ................................. 2.7Vrms @0dBFS (single-ended with adaptors,
“normal”)
5.4Vrms @0dBFS (single-ended with adaptors,
“high”)
5.4Vrms @0dBFS (balanced, “normal”)
10.8Vrms @0dBFS (balanced, “high”)
Output impedance: ........................... 100Ohm (single ended with adaptors)
200Ohm (balanced)
Signal-to-noise ratio:......................... 118dB (0dBFS, balanced, “A”-weighted)
114dB (0dBFS, single-ended, “A”-weighted)
THD+N:............................................. 0.0008% (-3dBFS, balanced, 1kHz)
0.003% (-3dBFS, single-ended, 1kHz)
Sampling frequency PCM: ................ 44.1, 48, 88.2, 96, 176.4*, 192*, 352.8**,
384**kHz
DSD formats ..................................... 64x, 128x**
PCM resolution ................................. 16 to 32 bit (USB)
16 to 24 bit (other inputs)
