Description Min Typical Max Unit
Input frequency 2412 2462 MHz
Output impedance - 50 -
Ω
Declare power
Output power of PA for 802.11b mode - 24.00 - dBm
Output power of PA for 802.11g mode - 24.00 - dBm
Output power of PA for 802.11n-HT20 mode - 24.00 - dBm
Output power of PA for 802.11n-HT40 mode - 20.50 - dBm
Sensitivity
DSSS，1Mbps
- -98 - dBm
CCK，11Mbps
- -91 - dBm
OFDM，6Mbps
- -93 - dBm
OFDM，54Mbps
- -75 - dBm
HT20,MCS0 - -93 - dBm
HT20,MCS7 - -73 - dBm
HT40,MCS0 - -90 - dBm
HT40,MCS7 - -70 - dBm
MCS32 - -89 - dBm
Adjacent channel rejection
OFDM，6Mbps
- 37 - dB
OFDM，54Mbps
- 21 - dB
HT20,MCS0 - 37 - dB
HT20,MCS7 - 20 - dB
