MA 4Port Node
Data
Transport
Safety
instructions
Safety and
environmet
Quickstart
Connect
Quickstart
ON / OFF
Maintenance
Conformity
27
Specification
Weight approx. 1,3 kg
Dimensions: 9“/1HU 207 x 43 x 184mm / 8.2 x 1.7 x 7.3 inch
4 DMX – OUT (XLR 5 pin) on the rear side. Each DMX OUT can be individually configured as DMX IN.
Ethernet RJ 45 network connector
USB Port connector on the front side. For update via USB-stick only. Do not connect any peripheral
device (mouse, keyboard or similar)
2“ TFT color monitor
2 048 Parameter (MA 4Port Node onPC)
