Page 10
PRINTED : JAN’2015 REF NO. SM7715010-01-11
Part Name
Defrost Sensor
Operating Procedure
- Follow step 1-10 of replacing Fan Blade.
- Follow step 1-2 of replacing Fan Motor.
1. Take out socket of Defrost sensor. 2. Cut out Cable Tie from Evaporator
tube.
3. Remove Al tape.
4. Pull Defrost Sensor from Evaporator
tube.
5. After replacing Bimetal Thermo, reverse the steps above.
