mabe ITV085ICER - Volume Assy Replacement

Page 15
PRINTED : JAN’2015 REF NO. SM7715010-01-11
Part Name
Volume Assy.
Operating Procedure
- Follow step 1-6 of replacing Chill LED Lights.
- Follow step 1-4 of replacing Ref sensor.
1. Pull out Socket. 2. Release screws. 3. Remove all Volume Assy.
4. Pull out Socket.
5. After replacing Volume Assy, reverse the steps above.
