47
2 3 41
Inlet
1
Air purifying filter
(inside)
4
Inlet grille
2
Outlet
3
Anion generator
(on some models)
5
Horizontal louvers
(Up and down airflow)
7
Vertical louvers
(Left and right
airflow)
6
Display
Emergency
switch
8
display board
display board C (on models having only LED
indicators)
Actual inlet grille may vary from the one shown in the manual ac-
cording to the product purchased.
1. Remote control signal receiver. A beep is heard when a signal
from the remote control is received.
2. Power indicator. Lights up when the unit starts.
3. TIMER mode indicator. Lights up when the TIMER operation is se-
lected.
4. Operation mode indicator. Lights up when the compressor is on.
