mabe MMI12CDMCCM9 - Parts and Features

46
5
6
2
3
4
1
2
1
3
Inlet Air purifying filter
(inside)
Inlet grille
Outlet
Horizontal louvers
(up and down airflow)
Vertical louvers
(left and right airflow)
Display
Emergency
switch
indoor unit
display board A
1. Signal receiver hole.
2. Ambient temp. display. When receiving the remote control signal,
display the set temperature.
3. COOL display.
4. HEAT display.
5. HEALTH display.
6. DRY display.
display board B
1. Signal receiver hole.
2. Ambient temp. display. When receiving the remote control signal,
display the set temperature.
3. Operation mode indicator (lights up when the compressor is on.)
