installation instructions
preparation
Necessary tools for installation
• Driver
• Nipper
• Hacksaw
• Hole core drill
• Spanner (17, 19 and 26 mm)
• Gas leakage detector or soap
and water solution
power source
• Before inserting the power plug into the receptacle, check the
voltage without fail. The power source must be the same as the
corresponding name plate.
• Install an exclusive branch circuit for the power.
• A receptacle must be set up in a distance where the power cable
can be reached. Do not extend the cable by cutting it.
• Torque wrench (17 mm, 22
mm, 26 mm)
• Pipe cutter
• Flaring tool
• Knife
• Measuring tape
• Reamer
selection of installation location
Indoor Unit
• Place, robust not causing vibration, where the body can be sup-
ported sufficiently.
• Place not affected by heat or steam generated in the vicinity,
where inlets and outlets of the unit are not disturbed.
• Place possible to drain easily, where piping can be connected with
the outdoor unit.
• Place where cold air can be spread in a room entirely.
• Place where the distance of more than 1 m from television sets, ra-
dios, wireless apparatuses and fluorescent lamps can be left.
• In the case of fixing the remote control on a wall, place where the
indoor unit can receive signals when the fluorescent lamps in the
room are lightened.
Outdoor Unit
• Place which is less affected by rain or direct sunlight, and is suffi-
ciently ventilated.
• Place sturdy enough to bear the unit, where vibration and noise
are not increased.
• Place where discharged wind and noise do not cause a nuisance to
the neighbors.
• Place where a distance marked is available as illustrated in the
above figure.
Important: The appliance must be installed in accordance with the
national regulations for electrical installations.
