Mac allister MLM1334 - Identifying Lawnmower Components

EN
12
Getting
started...
MLM1334
by MacAllister
Your product
1. Grip handle
2. Safety switch button
a. Cord retainer
3. Start lever (x2)
4. Power cord with plug
5. Upper handle bar
6. Clamp lever (x4)
a. Washer*
b. Mounting bolt*
7. Lower handle bar
(x2)
a. Indication line
(x3)*
8. Grass catcher
a. Carry handle
b. Top cover*
c. Rubber clip (x3)*
d. Supporting rod*
e. Hatch*
f. Screw*
g. Flat washer*
9. Transport handle
a. Indicator*
10. Rear wheel (x2)
11. Lever for cutting
height adjustment
12. Cutting blade
compartment
a. Spindle
b. Flange
c. Cutting blade
d. Hex nut
13. Front wheel (x2)
14. Motor housing
15. Deector guard
16. Inter-connection cord
17. Wire clip (x2)
18. Rear discharge chute
a. Hook (x2)
Your product
18a
18
12d 12c
12b
12a
1
2
2a
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
8a
