22
FRONT PANEL
LINE IN USB
1 2 3 4 5 6 7 8 9 10
1112
1 ON/STBY: Switches the device on when it is in the standby mode. Conversely the device
can be switched from power operation to the standby mode.
2 LINE IN: 3.5 mm stereo input jack for an auxiliary audio device (e.g. MP3 player, etc.).
3 USB INPUT: For connecting USB storage media.
4 CD COMPARTMENT: Insert the CD into the compartment with the label facing upwards.
5 SOURCE: Used for selecting the input source (CD, USB, FM, LINE IN, BT). This is indicated
on the display (12) briefly
6 PLAY/PAUSE: Starts or pauses the playback from a CD.
7 STOP: CD operation: Stops a CD that is playing.
