MacAllister MTC650 - Replacing the Cutting Disc

Fig. 17
Care and maintenance
MTC650 by MacAllister
29
In more detail…
> Raise the vertical fence (3) approx. 45° and remove.
> Place a suitable collector below the product's drain opening.
> Remove water reservoir plug (16) and drain off all the dirty cooling water.
> Filling the product with water (Refer to “Filling the product with water” section
on Page. 19-20).
WARNING: Risk of injury!
Never use segmented cutting discs.
WARNING: Risk of injury!
Always wear protective gloves when replacing the cutting disc.
WARNING: Risk of injury!
The metal bracket must always be aligned parallel to the cutting
disc.
Replacing the cutting disc
Removing the cutting disc：
> Raise the vertical fence (3) approx. 45° and remove.
3
EN
