MACHINIST X79-Z9-D7 User Manual

Any problem, please feel free to contact us.
—
1
—
Specifications
X79 Z9 D7
Processor
Supporting Intel Xeon E5 V1/V2 and Core i7 series CPU.
Southbridge
X79 Chipset
RAM
Technology
Dual Channel DDR3
Maximum
Capacity
64GB (16GB*4)
Memory Slot
4 * DDR3
Rear I/O
PS/2
Green: mouse. Purple: keyboard
Display Interface
N0
USB
6 * USB 2.0
Ethernet
1 * Gigabit LAN
AUDIO
1 (Mic-in, Line-out、Line-in)
Internal
connector
CFAN
1 * 4PIN
SFAN
2 * 3PIN
ATXPWR Interface
1 * 8PIN Power Socket；1 * 24PIN Power Socket
USB2.0(front)
3
USB3.0(front)
0
M.2
1 * NVME M.2(compatible with SATA M.2)
SATA Interface
1 * SATA 3.0, 3 * SATA 2.0
JAUDIO(front)
1
JLPC
1
JCMOS Port
1
PCIe
1 * PCIe x16; 1 * PCIe x1
BUZZER
1
Environment
Temperature
Range
Working Environment
Storage Environment
Temperature：0～50°C
Humidity：5%~95%
Temperature: -20~70°C
Humidity: 5%~95%
Physical Size
Size
235mm*185mm

MACHINIST X79-Z9-D7 Specifications

General

Brand	MACHINIST
Model	X79-Z9-D7
Category	Motherboard
Language	English
