Take Apart Analog Board & Power Supply - 6
3 Disconnect these cable
connectors from the
analog board:
Yoke cable (First
depress the tab.)
Logic board cable
Video board cable
Hard drive power
cable
Logic Board Cable
Power Cable
Hard Drive
Video
Board
Cable
Yoke Cable
