A-2
Components noted with this symbol shall be replaced only by the
component specifi ed. This is required to maintain product safety.
CFX•12
15 SEPTEMBER 2002
PART # REV DESCRIPTION QTY NOTES
070-120-XX A40 BOMSHELL CFX12 1 SEE BELOW
080-142-00 B TRANSFORMER ASSEMBLY -010 120V 1 SEE PAGE 12
510-001-00 B FUSE SB 1A 5X20MM 250V UL 1 FOR 120 VAC
640-001-00 D LC IEC SJT 10A/125V 6FT 1 LINECORD
820-104-00 C00 OWNERS MANUAL 1
090-120-00 REV A3 CFX12 FINAL ASSEMBLY
PART # REV DESCRIPTION QTY NOTES
040-358-00 B RIBBON CABLE 18G 7P .156 16IN 1
055-192-00-01 C11 EFFECTS ASSEMBLY 1 SEE PAGE 4
055-241-00-03 C05 MASTER PCB ASSEMBLY 1 SEE PAGE 5
055-242-00-02 C05 SLAVE PCB ASSEMBLY 1 SEE PAGE 9
055-258-00-01 A10 POWER SUPPLY ASSEMBLY 1 SEE PAGE 11
055-260-00-02 B00 AC INPUT ASSEMBLY 1 SEE PAGE 12
080-144-00 D BNC ASSEMBLY 1 SEE PAGE 12
400-365-00 A QDISK TAB .250 M #6 MNT 1
410-005-00 A INSL SILPAD TO-220 4
550-442-00 B1 SILKSCREENED CHASSIS TOP CXF 12 1
550-445-00 A1 CHASSIS BOTTOM CXF 12 1
550-462-00 A1 CLAMP TO-220 X 4 1
550-491-00 A1 FAB PLT HTSK CFX PWR SPLY 1
550-551-10 A1 PAINTED LEFT SIDE CFX 1
550-551-20 A1 PAINTED RIGHT SIDE CFX 1
550-552-00 B1 SILKSCREENED BACK CFX 12 1
620-045-00 A CBL FLT 14C W/PINS 3.5IN 2
700-010-00 A TF 6-32X1/4 PHP BLKZC 26
700-011-00 A MCH 4-40X1/4 BTNSKT BLKOX 34
700-028-01 B SEMS 6-32X5/16 PHP BLKZC 6
700-028-03 B SEMS 6-32X1/2 PHP BLKZC 4
701-016-00 A 5-20X5/16 PHPII TYP B BLK 23
705-001-00 A KEPNUT 6-32 4
0000223 A NUT, HEX, THREADED, 1/4” 0
705-008-00 A NUT LOCK 8-32 2
0000222 A WASHER 0
750-001-00 A FEET BUMPON ROUND BLK .63X.31 4
760-037-01 C00 KNOB SLIDE 10X25MM MLDLIN 11
760-037-03 C00 KNOB SLIDE 11X24 BLUE 4
070-120-XX REV A40 BOMSHELL CFX12
continued
