A-7
Components noted with this symbol shall be replaced only by the
component specifi ed. This is required to maintain product safety.
CFX•20
15 SEPTEMBER 2002
Master PCB assembly continued
PART # REV DESCRIPTION QTY NOTES
200-031-02 A PLY/BX .022UF 5% 100V TR 20
212-001-00 B1 CER .01UF 10% 50V X7R SM 83
212-003-00 B1 CER 100PF 5% 50V NPO SM 2
212-004-00 C1 CER 220PF 5% 50V NPO SM 4
212-005-00 B1 CER 20PF 5% 50V NPO SM 37
212-007-00 A1 CER .047UF 20% 50V Z5U SM 1
212-009-00 A CER 47PF 5% 50V NPO SM 24
212-010-00 B1 CER .1 +80/-20 25V Z5U SM 72
212-015-00 B1 CER 33PF 5% 50V NPO SM 2
212-018-00 B1 CER 10PF 5% 50V NPO SM 8
212-019-00 B1 CER 150PF 5% 50V SM 16
212-021-00 B1 CER 27PF 5% 50V NPO SM 12
212-023-00 B1 CER .001UF 10% 50V NPO SM 6
212-042-00 A1 CER 470PF 5% 50V NPO SM 16
220-002-02 A1 LYT 47UF 20% 25V RAD TR 135
220-003-02 B LYT 47UF 20% 50V RAD TR 8
220-004-02 C1 LYT 470UF 20% 6.3V RAD TR 4
220-008-02 A1 LYT 1UF 20% 50V RAD TR 2
220-013-02 A1 LYT .22UF 20% 50V RAD TR 12
220-027-02 B1 LYT 10UF 20% 50V RAD TR 6
300-003-00 A DIO SW DL4148 100V SM 8
301-004-00 A DIO PWR DL4002 SM 16
302-010-03 B DIO ZEN DL5232B 5.6V SM 2
304-002-00 A LED RED T1-3/4 W FLASHER 1
304-027-02 C00 LED RED W/.425 SPACER TR 5
304-028-02 C00 LED YEL W/.425 SPACER TR 7
304-029-02 C00 LED GRN W/.425 SPACER TR 20
310-002-02 A1 XSTR PNP 2N4403 T/A 2
311-001-00 B XSTR NPN IMBT4401 SMT 3
311-002-00 A XSTR PNP MMST4403 SMT 8
320-011-00 A OPAMP 4560 8P SIP 2
320-020-00 A IC, DUAL OP AMP NJM4565G 64
323-002-00 C LM339D QUAD COMP SM 8
325-086-03 A IC 74HC4053 ANA MUX/DEMUX 3
400-022-00 A RCA QUAD PCMNT 1
400-041-00 A XLR VERT MALE PCMNT 3
400-048-00 A HDR 7P .156X1 RTA 1
400-464-00 AO1 JACK 1/4 V PCMNT 1MM WASH 32
400-223-00 A XLR PCMNT NEUTRIK-AP SER 4
400-349-00 A HDR SKT BTTM ENTRY 14P .1 2
450-241-00 C PCB CFX MASTER 1
0000162 A SWITCH 2PDT PUSH V SNAPIN 46
500-045-00 A SW ROTARY ENCODER GREYCODE 15.5MM 1
601-010-00 A FERRITE SMT POWER 1
continued...
