Mackie CFX20 - Page 64

A-6
Components noted with this symbol shall be replaced only by the
component specifi ed. This is required to maintain product safety.
CFX•20
15 SEPTEMBER 2002
continued...
PART # REV DESCRIPTION QTY NOTES
140-112-00 A RES TF SM .1W 5% 39K OHM 2
140-114-00 A RES TF SM .1W 5% 47K OHM 16
140-119-00 A RES TF SM .1W 5% 75K OHM 8
140-123-00 A RES TF SM .1W 5% 100K OHM 69
140-130-00 A RES TF SM .1W 5% 200K OHM 6
141-051-00 B RES TF SM .25W 5% 120 OHM 34
145-066-00 B RES MF SM .1W 1% 4.75 OHM 4
145-279-00 B RES MF SM .1W 1% 787 OHM 2
145-288-00 B RES MF SM .1W 1% 976 OHM 2
145-296-00 B RES MF SM .1W 1% 1K18 OHM 2
145-307-00 B RES MF SM .1W 1% 1K54 OHM 2
145-317-00 B RES MF SM .1W 1% 1K96 OHM 2
145-330-00 B RES MF SM .1W 1% 2K43 OHM 6
145-339-00 B RES MF SM .1W 1% 3K01 OHM 22
145-341-00 B RES MF SM .1W 1% 3K16 OHM 1
145-346-00 B RES MF SM .1W 1% 3K57 OHM 4
145-350-00 B RES MF SM .1W 1% 3K92 OHM 2
145-352-00 B RES MF SM .1W 1% 4K12 OHM 4
145-356-00 B RES MF SM .1W 1% 4K53 OHM 2
145-358-00 B RES MF SM .1W 1% 4K75 OHM 2
145-368-00 B RES MF SM .1W 1% 6K04 OHM 2
145-373-00 B RES MF SM .1W 1% 6K81 OHM 1
145-377-00 B RES MF SM .1W 1% 7K50 OHM 2
145-388-00 B RES MF SM .1W 1% 9K76 OHM 5
145-389-00 B RES MF SM .1W 1% 10K0 OHM 16
145-397-00 B RES MF SM .1W 1% 12K1 OHM 4
145-406-00 B RES MF SM .1W 1% 15K0 OHM 4
145-416-00 B RES MF SM .1W 1% 19K1 OHM 2
145-417-00 B RES MF SM .1W 1% 19K6 OHM 2
145-418-00 B RES MF SM .1W 1% 20K0 OHM 8
145-426-00 B RES MF SM .1W 1% 24K3 OHM 4
145-435-00 B RES MF SM .1W 1% 30K1 OHM 4
145-445-00 B RES MF SM .1W 1% 38K3 OHM 4
145-455-00 B RES MF SM .1W 1% 48K7 OHM 2
145-456-00 B RES MF SM .1W 1% 49K9 OHM 6
145-464-00 B RES MF SM .1W 1% 60K4 OHM 2
145-474-00 B RES MF SM .1W 1% 76K8 OHM 2
146-373-00 A RES MF SM .25W 1% 6K81 OM 8
200-010-02 B PLY .0018UF 10% 100V TR 8
200-011-02 B PLY .0022UF 10% 100V TR 12
200-013-02 B PLY .0082UF 10% 100V TR 8
200-014-02 B PLY .0033UF 10% 100V TR 8
200-025-02 A PLY/BX .56UF 5% 63V TR 8
200-029-02 A PLY/BX .22UF 5% 50V TR 15
Master PCB assembly continued
