A-5
Components noted with this symbol shall be replaced only by the
component specifi ed. This is required to maintain product safety.
CFX•20
15 SEPTEMBER 2002
continued...
055-241-00-03 REV C05 MASTER PCB ASSEMBLY
PART # REV DESCRIPTION QTY NOTES
040-357-00 A DIS 22GA 1007 GRN/Y 8 QD 1
130-002-02 A POT RTY 50KB 9MM MNO H TN 12
130-003-02 A POTRTY 50KG 9MM MN TN PAN 36
130-022-02 A POT RTY 10KB 9MM MONO TN 2
130-030-02 A POT RTY 5KZY 9MM MNO H TN 4
130-031-00 A POT SLIDE 10KD 60MM MONO 8
130-032-00 A POT SLIDE 50KD 60MM DUAL 3
130-061-02 B POT 50KG 12MM DUAL WO SLV 15
130-064-02 A POT 500KC 12MM DUL WO SLV 4
130-075-00 A POT SLD 50KG 30MM DL PANS 9
140-017-00 A RES TF SM .1W 5% 4.7 OHM 4
140-032-00 A RES TF SM .1W 5% 20 OHM 1
140-037-00 A RES TF SM .1W 5% 33 OHM 1
140-049-00 A RES TF SM .1W 5% 100 OHM 1
140-051-00 A RES TF SM .1W 5% 120 OHM 13
140-057-00 A RES TF SM .1W 5% 220 OHM 2
140-061-00 A RES TF SM .1W 5% 330 OHM 2
140-064-00 A RES TF SM .1W 5% 430 OHM 1
140-065-00 A RES TF SM .1W 5% 470 OHM 3
140-066-00 A RES TF SM .1W 5% 510 OHM 53
140-068-00 A RES TF SM .1W 5% 620 OHM 1
140-073-00 A RES TF SM .1W 5% 1K0 OHM 64
140-074-00 A RES TF SM .1W 5% 1K1 OHM 2
140-076-00 A RES TF SM .1W 5% 1K3 OHM 1
140-077-00 A RES TF SM .1W 5% 1K5 OHM 2
140-079-00 A RES TF SM .1W 5% 1K8 OHM 4
140-080-00 A RES TF SM .1W 5% 2K0 OHM 8
140-083-00 A RES TF SM .1W 5% 2K7 OHM 2
140-085-00 A RES TF SM .1W 5% 3K3 OHM 2
140-086-00 A RES TF SM .1W 5% 3K6 OHM 4
140-087-00 A RES TF SM .1W 5% 3K9 OHM 17
140-088-00 A RES TF SM .1W 5% 4.3K OHM 8
140-089-00 A RES TF SM .1W 5% 4K7 OHM 40
140-090-00 A RES TF SM .1W 5% 5K1 OHM 72
140-091-00 A RES TF SM .1W 5% 5K6 OHM 1
140-094-00 A RES TF SM .1W 5% 7K5 OHM 16
140-097-00 A RES TF SM .1W 5% 10K OHM 108
140-098-00 A RES TF SM .1W 5% 11K OHM 12
140-101-00 A RES TF SM .1W 5% 15K OHM 12
140-104-00 A RES TF SM .1W 5% 20K OHM 12
140-105-00 A RES TF SM .1W 5% 22K OHM 1
140-108-00 A RES TF SM .1W 5% 27K OHM 4
140-109-00 A RES TF SM .1W 5% 30K OHM 32
140-111-00 A RES TF SM .1W 5% 36K OHM 8
