A-9
Components noted with this symbol shall be replaced only by the
component specifi ed. This is required to maintain product safety.
CFX•20
15 SEPTEMBER 2002
continued...
PART # REV DESCRIPTION QTY NOTES
130-002-02 A POT RTY 50KB 9MM MNO H TN 12
130-003-02 A POTRTY 50KG 9MM MN TN PAN 20
130-030-02 A POT RTY 5KZY 9MM MNO H TN 4
130-031-00 A POT SLD 10KD 60MM MONO 4
130-064-02 A POT 500KC 12MM DUL WO SLV 4
140-066-00 A RES TF SM .1W 5% 510 OHM 32
140-073-00 A RES TF SM .1W 5% 1K0 OHM 24
140-080-00 A RES TF SM .1W 5% 2K0 OHM 4
140-087-00 A RES TF SM .1W 5% 3K9 OHM 8
140-089-00 A RES TF SM .1W 5% 4K7 OHM 28
140-090-00 A RES TF SM .1W 5% 5K1 OHM 32
140-094-00 A RES TF SM .1W 5% 7K5 OHM 4
140-097-00 A RES TF SM .1W 5% 10K OHM 12
140-098-00 A RES TF SM .1W 5% 11K OHM 4
140-101-00 A RES TF SM .1W 5% 15K OHM 4
140-104-00 A RES TF SM .1W 5% 20K OHM 8
140-108-00 A RES TF SM .1W 5% 27K OHM 4
140-111-00 A RES TF SM .1W 5% 36K OHM 4
140-114-00 A RES TF SM .1W 5% 47K OHM 8
140-123-00 A RES TF SM .1W 5% 100K OHM 24
141-051-00 B RES TF SM .25W 5% 120 OHM 4
145-066-00 B RES MF SM .1W 1% 4.75 OHM 4
145-339-00 B RES MF SM .1W 1% 3K01 OHM 20
145-346-00 B RES MF SM .1W 1% 3K57 OHM 4
145-352-00 B RES MF SM .1W 1% 4K12 OHM 4
145-389-00 B RES MF SM .1W 1% 10K0 OHM 16
145-418-00 B RES MF SM .1W 1% 20K0 OHM 8
146-373-00 A RES MF SM .25W 1% 6K81 OM 8
200-010-02 B PLY .0018UF 10% 100V TR 4
200-014-02 B PLY .0033UF 10% 100V TR 8
200-025-02 A PLY/BX .56UF 5% 63V TR 4
212-001-00 B1 CER .01UF 10% 50V X7R SM 34
212-004-00 C1 CER 220PF 5% 50V NPO SM 4
212-005-00 B1 CER 20PF 5% 50V NPO SM 4
212-009-00 A CER 47PF 5% 50V NPO SM 8
212-010-00 B1 CER .1 +80/-20 25V Z5U SM 4
212-018-00 B1 CER 10PF 5% 50V NPO SM 4
212-019-00 B1 CER 150PF 5% 50V SM 16
212-023-00 B1 CER .001UF 10% 50V NPO SM 4
212-042-00 A1 CER 470PF 5% 50V NPO SM 16
220-002-02 A1 LYT 47UF 20% 25V RAD TR 38
220-003-02 B LYT 47UF 20% 50V RAD TR 8
220-004-02 C1 LYT 470UF 20% 6.3V RAD TR 4
220-013-02 A1 LYT .22UF 20% 50V RAD TR 12
055-242-00-02 REV C05 SLAVE PCB ASSEMBLY
