Components noted with this symbol shall be replaced only by the
component specifi ed. This is required to maintain product safety.
CFX•16 Parts List
PART # DESCRIPTION PAGE
090-121-0 CFX16 2
070-121-XX BOMSHELL CFX16 2
055-192-00-01 EFFECTS PCB ASSEMBLY 4
055-241-00-03 MASTER PCB ASSEMBLY 5
055-242-00-02 SLAVE PCB ASSEMBLY 9
055-258-00-01 POWER SUPPLY PCB ASSEMBLY 11
080-144-00 BNC ASSEMBLY 12
055-260-00-02 AC INPUT PCB ASSEMBLY 12
080-142-00 TRANSFORMER ASSY -010 120V 12
