A-4
Components noted with this symbol shall be replaced only by the
component specifi ed. This is required to maintain product safety.
CFX•16
15 SEPTEMBER 2002
PART # REV DESCRIPTION QTY NOTES
140-009-00 A RES TF SM .1W 5% 2.2 OHM 1
140-049-00 A RES TF SM .1W 5% 100 OHM 2
140-053-00 A RES TF SM .1W 5% 150 OHM 2
140-073-00 A RES TF SM .1W 5% 1K0 OHM 6
140-089-00 A RES TF SM .1W 5% 4K7 OHM 10
140-097-00 A RES TF SM .1W 5% 10K OHM 2
140-114-00 A RES TF SM .1W 5% 47K OHM 4
140-123-00 A RES TF SM .1W 5% 100K OHM 3
140-139-00 A RES TF SM .1W 5% 470K OHM 1
212-001-00 B1 CER .01UF 10% 50V X7R SM 2
212-003-00 B1 CER 100PF 5% 50V NPO SM 2
212-005-00 B1 CER 20PF 5% 50V NPO SM 2
212-007-00 A1 CER .047UF 20% 50V Z5U SM 1
212-016-00 A1 CER 1000PF 5% 5OV NPO SM 13
212-023-00 B1 CER .001UF 10% 50V NPO SM 3
212-024-00 A1 CER 1UF 25V Y5V 1206 4
212-027-00 A1 CER .1UF 16V 10% X7R 0603 15
212-029-00 A1 CER 270PF 5% 50V NPO SM 2
212-032-00 A1 CER 2200PF 10% 50V X7R 5
223-003-00 A1 LYT 22UF 20% 6.3V SM 1
223-004-00 B1 LYT 10UF 20% 16V SM 5
300-003-00 A DIO SW DL4148 100V SM 4
325-027-03 A CMOS 74HC74A DUAL D FLPFL 1
325-071-03 A CMOS 74HCU04 HEX INV SM 1
329-042-03 B CODEC SOUNDPORT AD1819 1
329-047-03 B SRAM 32KX8 20NS SOJ SM 2
450-192-00 C PCB LC EFTS PWR MIXER 1
601-009-00 A FERRITE SMT SIG 1K OHM 3
601-010-00 A FERRITE SMT POWER 1
080-088-00 A DSP PROGRAMMED ADSP-2163 1
050-192-00-01 REV C11 EFFECTS PCB ASSEMBLY
PART # REV DESCRIPTION QTY NOTES
220-011-00 A1 LYT 100UF 20% 25V RAD 1
315-017-00 A XTAL 24.576MHZ LOW PROF 1
400-280-00 A HDR SKT 16P .1X1 STR 1
050-192-00-01 C11 EFFECTS PCB ASSEMBLY 1 SEE BELOW
055-192-00-01 REV C11 EFFECTS ASSEMBLY
