A-11
Components noted with this symbol shall be replaced only by the
component specifi ed. This is required to maintain product safety.
CFX•16
15 SEPTEMBER 2002
PART # REV DESCRIPTION QTY NOTES
100-028-00 A RES CF .125W 5% 130 OHM 2
100-031-00 A RES CF .125W 5% 180 OHM 1
100-058-00 A RES CF .125W 5% 2K4 OHM 2
100-063-00 A RES CF .125W 5% 3K9 OHM 2
110-080-00 A RES CF .25W 5% 20K OHM 1
121-093-00 A RES MO 1W 5% 6K8 OHM 1
211-001-00 D1 CER .01UF +80/-20% 25V AX 3
211-010-00 A1 CER .01UF +80/-20% 50V AX 1
220-002-02 A1 LYT 47UF 20% 25V RAD TR 1
220-007-00 B1 LYT 100UF 20% 100V RAD 1
220-011-02 A1 LYT 100UF 20% 25V RAD 2
220-012-02 B1 LYT 4.7UF 20% 63V RAD TR 1
220-023-00 C1 LYT 6800UF 20% 35V RAD 3
220-026-00 B1 LYT 1000UF 20% 100V RAD 1
220-027-02 B1 LYT 10UF 20% 50V RAD TR 2
301-001-00 A DIO PWR 1N4002 17
301-003-00 B DIO PWR 1N5401 3A 100V 4
321-003-00 B REG 7805 +5V 1
321-008-00 B REG LM317T ADJ 2
321-009-00 A REG LM337T ADJ 1
400-060-00 A FUSE CLIP PCMT 5MM DIA 2
400-093-00 A HDR 7P .156X1 LOCKING 1
400-173-00 A TERM .25 QKDS PCMT STABLE 1
400-348-00 A TERM .187 QDISC STBL PCMT 1
400-350-00 A HDR 9P .156X1 STR 1
450-258-00 B PCB PWR SPLY CMPT CFX 1
510-002-00 C FUSE SB .5A 5X20 250V IEC 1
055-258-00-01 REV A10 POWER SUPPLY PCB ASSEMBLY
