PLEASE! SAVE THE
SHIPPING BOX!
Top Ten Reasons for
saving your shipping box:
10. It’s here.
9. It’s yours.
8. It’s paid for.
7. It’s strong and sturdy.
6. It fits your mixer perfectly.
5. You will need it if you ever ship your mixer.
4. We may have to sell you another one if you
need to ship your mixer and you don’t have
it.
3. It will impress your friends who have no
lives when they see it in your basement.
2. It’s the ecologically sound thing to do.
1. It’s the Mackie sound thing to do.
Top Ten Reasons for
not
saving your
shipping box:
10. Your cat has already used it.
9. You stole the mixer out of a Karaoke bar.
8. Your Mackie mixer will never break.
7. You will never move again.
6. You wrote a song on it and are considering
framing it.
5. You have cut off the top and are using it as
an equipment rack.
4. You really hate planning ahead because it
never works out anyway.
3. It fits some other manufacturer’s product,
which is broken, perfectly.
2. You have kept all the boxes of all the other
equipment you have ever bought and you
have never used one of them ever.
1. You are afraid of corrugated products.
LAYOUT
AND
FUNCTION
APPENDICES
GENERAL
INFO
PANEL LAYOUT AND
FUNCTION
GENERAL
INFORMATION
USING THE
LM-3204
CONNECTIONS, OPTIONS,
SPECS, AND SERVICE
TABLE OF CONTENTS
SECTION 1:
Introduction ..................................................... 4
Sensitivity Adjustments .................................... 5
SECTION 2:
Panel Layout & Function.................................. 6
Input module (channel strip).................. 6
Master output section................................ 9
Rear Panel ................................................12
SECTION 3:
General Information........................................16
SECTION 4:
Using the LM-3204 ..........................................19
Instrument submixer, stage.....................19
Instrument submixer, studio...................20
Effects submixer, studio ...........................20
Main mixer, studio...................................20
Club sound reinforcement mixers...........20
Other applications....................................21
APPENDIX A:
Connections ....................................................30
APPENDIX B:
Options, Add-Ons and Extra Stuff ...................33
APPENDIX C:
Specifications, Tech Stuff................................34
APPENDIX D:
Service ............................................................38
USING THE
LM-3204
To Next Page
