Mackie Mix5 Manual

8/12 PAGES
Compact Mixers
PHANTOM
MIC IN
+48 VDC
LINE IN LINE IN LEFT (MONO) LINE IN RIGHT AUX RETURN LEFT (MONO) AUX RETURN RIGHT
PEAK
PEAK
MONO CHANNELS
1 and 2
GAIN
EQ
HIGHMID
80
12K2.5K
LOW
EQ
HIGHMID
80
12K2.5K
LOW
PAN
LEVEL
LEVEL
AUX
MAIN MIX
STEREO CHANNELS AUX RETURNS
3/4 and 5/6
L
L
R
R
PAN
AUX
L
R
L
R
LEFT MAIN BUS
RIGHT MAIN BUS
AUX BUS
AUX SEND
HEADPHONE OUTPUT
LEFT
RIGHT
METERS
TAPE TO CTRL RM/ PHONES
TAPE TO MIX
CONTROL
ROOM/
PHONES
LEFT MAIN MIX OUT
RIGHT MAIN MIX OUT
LEFT CONTROL ROOM OUTPUTS
RIGHT
CD/TAPE OUT
LEFT
RIGHT
CD/TAPE IN
MASTER AUX SEND
LEVEL
Mix8 Block Diagram

Mackie Mix5 Specifications

General

Frequency range	20 - 30000 Hz
Channels quantity	5 channels
Line inputs (RCA)	1
Equalizer bands quantity	2
Microphone input impedance	2000 Ω
DJ mixer	-
Product color	Black
Video capability	No

Weight and Dimensions

Depth	196 mm
Width	140 mm
Height	43 mm
Weight	600 g
Package depth	287 mm
Package width	165 mm
Package height	84 mm
Package weight	900 g
