General Digital
Sample Rate 48 kHz
A/D/A Bit Depth 24-bit
System Latency <2 ms
Frequency Response
All inputs to all outputs 20 Hz to 20 kHz, ±1 dB
Noise / Crosstalk / Dynamic Range
THD+N
Mic input to Main output, –25 dBu input <0.005%
(20 Hz – 20 kHz, A-weighted)
Crosstalk
Adjacent Inputs <–85 dB
Outputs <–85 dB
Dynamic Range
Mic input to Main output, A-weighted 105 dB
Maximum Levels (1% THD+N)
XLR Inputs –12 dBu
1/4" Inputs +14 dBu
1/8" Input +9 dBu
Main Out +14 dBu
Aux Out +14 dBu
Headphone Out 180 mW into 600
Impedances
XLR 10 k balanced
1/4" >5 M
unbalanced
1/8" 9 k
unbalanced
Phones output 10
unbalanced
All other outputs 100
unbalanced /
200
balanced
Channel Processing
Low Cut Off, 20 Hz – 400 Hz,
12 dB / octave
Low Shelving ±12 dB @ 80 Hz
Mid-Peaking ±12 dB sweep
100 Hz – 8 kHz
High Shelving ±12 dB @ 12.5 kHz
Compression Single slider, off to max
System Processing
FX 16 presets
Output GEQ 7-Band, ±12 dB,
125, 250, 500, 1k, 2k, 4k, 8k
Memory Presets 3
Power
External Supply
Power Requirements 100 – 240 VAC, 50/60 Hz,
Universal Supply,
18VDC, 0.5 Amps
Operating Temperature 0˚ – 40˚C
32˚ – 104˚F
Bluetooth Information
Bluetooth Protocol 3.0
Bluetooth Function Audio Streaming and
User Interface Control
Physical Properties
ProDX4
Height 3.0 in / 76 mm
Width 6.3 in / 160 mm
Depth 5.5 in / 140 mm
Weight 2.2 lb / 1.0 kg
ProDX8
Height 3.0 in / 76 mm
Width 9.1 in / 230 mm
Depth 5.5 in / 140 mm
Weight 3.2 lb / 1.5 kg
Options
ProDX4 Bag P/N 2036809-40
ProDX8 Bag
P/N 2036809-40
Disclaimer
Since we are always striving to make our products better
by incorporating new and improved materials, components,
and manufacturing methods, we reserve the right to change
these specifications at any time without notice.
The “Running Man” figure is a registered trademark of LOUD
Technologies Inc.
All other brand names mentioned are trademarks or registered
trademarks of their respective holders, and are hereby
acknowledged.
©2016 LOUD Technologies Inc.
All Rights Reserved.
