Active Speaker System
SA1521
SPEAKER
SA1521
oF 6 PAGES
2
O F 6 P A G E S
Active Speaker System
SA1521
oF 6 PAGES
3
O F 6 P A G E S
Active Speaker System
SA1521
oF 6 PAGES
4
O F 6 P A G E S
Horn Design
Horizontal Coverage 75° 1kHz to 6kHz avg.
Vertical Coverage 65° 1kHz to 6kHz avg.
Type Constant Directivity
Mouth Size 10.6" x 10.6"
(27 x 27cm)
Throat size 1.0" (2.54 cm)
Low Frequency Section
Number of Drivers 1
Woofer Size 15"
Diaphragm Material Epoxy-reinforced
Cellulose
Magnet Type Ferrite
Construction Features
Basic Design Trapezoidal
Material 13-ply Baltic birch/ resin end caps
Finish Wear-resistant black PVC vinyl
Handles Two on sides, One top, One bottom
Grille Perforated metal with weather-
resistant coating
Line Input Power
Power Consumption 190W long term with IEC
pink noise and limiter on
US 120 VAC, 60Hz
Recommended amperage service 13 Amps
Europe 230 VAC, 50Hz
Recommended amperage service 7 Amps
AC connector 3-pin IEC 250 VAC
Control System Function
Electronic Crossover
Phase Alignment
Time Correction
Equalization
Parametric equalization
Safety Features
Protection Low Frequency Dynamic Bass
Protection, RMS Limiting, Power
Supply and Amplier Thermal
Protection
Display LEDs Signal Present, Limit, Power ON, and
Thermal (Cool Down Auto Reset)
Physical
Height 32.0 in/81.3 cm
Width Front 19.1 in/48.5 cm
Width Back 13.9 in/35.3 cm
Depth 18.1 in/46.0 cm
Weight 101.0 lb/45.8 kg
SA1521 Specications
System Acoustic
–3dB response 57Hz-18kHz
–10dB response 49Hz-20kHz
Directivity Factor; Q (DI) 14.4 (11.6), averaged
2kHz to 10kHz
System Sensitivity
1
100 dB, 1W@1m
Max SPL long-term 130 dB
Max SPL Peak 133 dB
Crossover Linkwitz-Riley, 24 dB/octave @ 1300Hz
Input /Output
Input Bal./unbal. Female XLR
Loop-through (parallel w/input) Bal./unbal. Male XLR
Level Control Rotating knob (–15 to +5 dB),
center detent @ 0 dB
Ampliers
Total Amplier Power 500 watts Continuous*
High Frequency 100 watts*
Type Class AB
Rated THD .03%
Low Frequency 400 watts*
Type Class G Hybrid
Rated THD 0.03%
*Rated power is continuous RMS wattage into transducer’s
rated impedance @ 1kHz for the HF amplier and @ 100Hz for
the LF amplier
High Frequency Section
Diaphragm Size 1.75"
Horn Exit Diameter 1.0"
Phase Plug 3-Slot Optimized
Geometry
Diaphragm Material Damped titanium
Magnet Type Ferrite
1
Measured on-axis in the far eld, referenced back to 1 watt RMS from maxi-
mum power and to 1 meter distance using the inverse square law.
 The SA1521 cabinet is constructed using both multi-
layered plywood and pressure injected structural resin. The
combination provides a robust enclosure with useful ergo-
nomic features. There are three-part cast aluminum handles
on each side of the enclosure placed at the speaker’s center
of gravity for easy carrying and setup. Handles are also locat-
ed on the top and bottom of the cabinet for easy movement
and relocation. A built-in pole-mount cup is provided on
the bottom, and a full-size, oval punched, weather-resistant
steel grille protects the front of the cabinet.
