SRM | V-Class High-Performance Powered Loudspeaker Series
18
SRM | V-Class High-Performance Powered Loudspeaker Series
ZONE: The zone mode setting is your optional
loudspeaker setup, ideal for when the speakers
are placed in dierent locations and allows for
separate main level controls.
SRM | V-Class loudspeakers in zone mode
setting will receive a mono-summed signal.
The following channels are available when the
SRM | V-Class loudspeakers are linked in zone mode:
• Ch.  Primary or Secondary
• Ch. 2 Primary or Secondary
• Bluetooth Primary or Secondary
• Primary or Secondary Main
As before, illuminating and selecting the lef-facing
arrow returns you to the previous screen.
Configuration
This is where to select the Ch.  and 2 input settings,
front LED status and color, LCD brightness, lock access
to the settings, auto connect / link bluetooth and more.
This is similar to what you will see afer first entering
the configuration screen. The current selection of the
top five features will be illuminated.
To change a setting, just rotate the speaker
control knob until the configuration you desire
to change is illuminated, then push to select it.
MODE SUB
DELAY
BT
MIXER
CONFIG
CONFIGURATION
CH1 IN
ABOUT/RES...
FRONT LED
CH2 IN
LED COLOR
LCD SCREEN
BT SETTINGS...
LOCK...
LINE MIC
HI DIM OFF
GRN WH MUL
ON OFF SIG
LINE HI-Z
These are the choices from top to bottom:
Ch 1 in – As mentioned a few pages back, the channel
 input accepts both XLR and /4" inputs. In addition
to setting each channel’s gain knob to the correct
setting, be sure to set it here, as well. The selection
will illuminate green; line on the lef, mic on the right.
Illuminating and selecting the lef-facing arrow
returns you to the previous screen.
More information about the channel inputs
may be found on pages 0-.
Ch 2 in – In addition to the previously mentioned
channel  input, the channel 2 input allows
instruments to be connected directly into the /4" jack.
To connect an instrument directly without using a DI
Box, set channel 2’s gain knob to Hi-Z and change
the channel 2 input setting to Hi-Z. The Hi-Z text will
illuminate to indicate that Hi-Z is active. Next connect
the output from the instrument to the channel 2 /4"
input. The input impedance is optimized for direct
connection and high-frequency fidelity is assured.
Guitars may sound dull and muddy without a DI
box or if Hi-Z is not engaged. When not set at Hi-Z,
the channel 2 /4" input become a line input, as seen
below.
Illuminating and selecting the lef-facing arrow
returns you to the previous screen.
More information about the channel inputs
may be found on pages 0-.
CONFIGURATION
ABOUT/RES...
FRONT LED
CH2 IN
LED COLOR
LCD SCREEN
BT SETTINGS...
LOCK...
HI DIM OFF
GRN WH MUL
ON OFF SIG
LINE HI-Z
CH1 IN LINE MIC
CONFIGURATION
ABOUT/RES...
FRONT LED
LED COLOR
LCD SCREEN
BT SETTINGS...
LOCK...
HI DIM OFF
GRN WH MUL
ON OFF SIG
CH1 IN LINE MIC
CH2 IN LINE HI-Z
