Contents
1. Contents P1
2. Please read first P1
3. Specification P2
4. Safety P2
4.1 Specified conditions of use P2
4.2 General safety instructions P2
4.3 Symbols used throughout these instructions P4
4.4 Safety devices P4
5. Unpacking P4
6. Special product features P4
7. Operation elements P4
8. Initial operation P5
8.1 Replacing the fuse in the switch box P5
8.2 Installing the extension table P6
8.3 Installing the front rail P6
8.4 Installing the rear rail P7
8.5 Installing the long and short rail P7
8.6 Installing the sliding table P8
8.7 Aligning sliding table P8
8.8 Installing the lateral fence P9
8.9 Installing the rip fence P9
8.10 Installing blade guard P10
8.11 Connection of dust collector P10
8.12 Mains connection P10
9. Operation P10
9.1 Sawing P11
9.2 Mitre cuts P11
9.3 Rip cuts with rip fence P11
10. Care and maintenance P12
10.1 Saw blade change P12
10.2 Cleaning the saw P13
10.3 Machine storage P13
10.4 Maintenance P13
11. Tips and tricks P13
12. Repairs P13
13. Trouble shooting P14
14. transportation P16
15. Circuit diagrams P16
16. Instruction for thermo cutout in motor P16
17. Diagrams and parts lists P1
7
2.Please Read First
WARNING!
When using electric tools basic safety
Precautions should always be followed to reduce the risk
of fire,electric shock and personal injury including the
following.
·Read these instructions before attempting to operate
this product and save these instructions.
·If you notice transport damage while unpacking,notify
your supplier immediately.Do not operate the saw!
·Dispose of the packing in an environmentally friendly
manner.Take to a proper collecting point.
·Keep these instructions for reference on any issues you
may be uncertain about.
ATTENTION：
FOR YOUR OWN SAFETY ： READ AND
UNDERSTAND THE OWNER’S MANUAL BEFORE
OPERATING MACHINE.
1. Set up the saw on a firm,level,non-slip,vibration-free
base.Keep the site free of tripping hazards.Ensure
adequate lighting conditions.
2. Do not wear loose fitting clothes,remove rings,
wristwatch and bracelets.Tie back long hair.
3. Wear safety goggles and face shield if operation is
dusty.Wear ear defenders.
4. Do not use the saw in a moist or wet environment,
or in the vicinity of combustible liquids and gases.
5. The saw must only be operated with all correctly
mounted guards.
6. Never use cracked or distorted saw blades.Only user
sharp saw blades.
7. Use a pushing stick when rip sawing narrow
work-piece.
Limitations on ambient conditions
The circular saw bench is designed for operating on the
site;
The height above sea level doesn’t exceed 1000m;
The temperature range of air doesn’t exceed
0°c～40°c.
